Concrete Boom Pump Twin Wall Pipe for /Pm/Schwing

Short Description:

Port: Tianjin, China

Production Capacity: 500PCS/Per Day
Payment Terms: L/C, T/T, D/P, Western Union, Paypal, Money Gram
Compound Material: Steel Chrome Composize Pipe
Material: 20# St52+Nm600
Thickness: 8.1mm
Wall Thinkness(Shell+Inner): 3.0+5.1mm
Length Deviation: +-1mm
Length(in/mm): 118.12/3000 or Customized


Product Detail

Product Tags

Basic Info

Model NO.
DN125 8.1mm (5.1m + 3.0mm)

Hardeness
up to 68HRC

Hardened Process
UHF Quenching (400kHz)

Theoretical Weight(Lbs/Kg)
101/46

Flange Tape
Sk148 HD157 Zx175 FM175

Weld Tensile Strength
>480bar

Test Pressure
170bar

Color
Red Black White or Customized

Surface Coating
Baking Paint

Trademark
Ximai

Transport Package
Standard Export Package

Specification
DN125/5"

Origin
China

HS Code
841391

Product description
High quality twin wall concrete pump pipes
TWIN WALL DECK PIPE DN125 8.1mm (5.1m + 3.0mm) with 148mm chrome alloy liner weld ends
Part Number Length(in/mm) Theoretical weight(lbs./kg.) HardenedProcess HardnessHRC LengthDeviation TestPressure WeldTensileStrength SurfaceCoating
TW810W50L1M 39.37/1000 57/26 UHF Quenching(400KHz) UP to 68 ±1mm 280bar >480bar Baking paint
TW810W50L2M 78.75/2000 117/53 UHF Quenching(400KHz) UP to 68 ±1mm 280bar >480bar Baking paint
TW810W50L3M 118.12/3000 172/78 UHF Quenching(400KHz) UP to 68 ±1mm 280bar >480bar Baking paint
TW810W50L4M 157.48/4000 230/104 UHF Quenching(400KHz) UP to 68 ±1mm 280bar >480bar Baking paint
TW810W50L6M 236.22/6000 344/156 UHF Quenching(400KHz) UP to 68 ±1mm 280bar - Primer
Any length can be customized,please consult us.

1.We are a professional manufacturer of concrete pump pipes in China.Our products include delivery pipes,elbows,reducers,couplings,rubber hoses,cleaning ball and so on.

2.Our products are top quality in china which have been used on SCHWING ,PM ,KYOKUTO ,SANY ,ZOOMLION ,CIFA,SINOTRUK(CNHTC),FOTON,XUGONG,CHUTIAN,HAINUO etc and have been recognized by them.

3.The HRC of it’s inner wall can reach 60~68 degrees and the serving life of it can increase 3~5 times.

4.It is quenched and carried out carburizing chemical treatment on the inner wall.It has a high wear-resistant.

5.OEM available from us.Production displayConcrete Boom Pump Twin Wall Pipe for /Pm/SchwingConcrete Boom Pump Twin Wall Pipe for /Pm/Schwing

Product process Concrete Boom Pump Twin Wall Pipe for /Pm/SchwingProduct testConcrete Boom Pump Twin Wall Pipe for /Pm/SchwingPackaging&ShippingConcrete Boom Pump Twin Wall Pipe for /Pm/SchwingConcrete Boom Pump Twin Wall Pipe for /Pm/SchwingContact us Concrete Boom Pump Twin Wall Pipe for /Pm/Schwing
